Single Jersey Computerized Jacquard Circular Knitting Machine

Single Jersey Computerized Jacquard Circular Knitting Machine

Single Jersey Computerized Jacquard Circular Knitting Machine


Varying jacquard patterns can be input and easily changed on the machine to keep up with the fashion trends. Gear and other main components are made in Taiwan or imported from Japan or Germany brands, making you to get high quality fabric through stable performance.

  • No special drawing software required to make various graphic patterns
  • Advanced Control System to facilitate easy operation
  • High accuracy needle selection
  • Application Area: fashion clothes and underwear

  • Applicable Yarn Materials: cotton, synthetic fiber, silk, artifical wool, mesh or elastic cloth.

Download Specifications Inquire This Item

Advanced needle selection system

Enable unrestricted jacquard patterns fabric, meet different demands on the market

3 technical ways

Enable various jacquard fabrics, high utilization; save time for changing jacquard pattern

Precise encoder

Accurately check the needle position, maintain machine stability; less breakdown

Main Features


Unlimited jacquard-patterned fabrics

Unlimited jacquard-patterned fabrics

Adopting Sintelli’s advanced computerized on-cylinder needle-picking system, this single electronic jacquard knitting machine can knit unrestricted jacquard-patterned fabric. The Japanese computerized needle selection system has three-position needle selection options - knit, tuck, and miss, allowing any complex fabric patterns to be converted via this jacquard preparation system into dedicated control commands. These commands will then be stored on the disk which controls the knitting machines, ensuring your machine can knit any patterns, as specified by the customer.

High-speed CAM system

High-speed CAM system

The professionally-designed high-speed CAM system limits needle loss. Components for the drive system are made of superior-quality tempered materials. Gears and other main components are made in Taiwan and bearings are imported from Japan. All of these parts give our machine a high-precision drive system, stable performance and low running noise.

  • Model Cylinder Diameter Machine Gauges No. of Feeders Speed
    SJCJ 30’’- 38’’ 12-30G 60-72 F/Inch 15-22 RPM
  • Application Area: fashion clothes and underwear

    fabric-jacquard

    single-jacquard-fabric

  • Equipment STANDARD OPTION A OPTION B
    Needle Groz Beckert, Germany Samsung, Korea Yantex, Korea
    Sinker (For single knit) Kern Libbers, Germany Samsung, Korea Yantex, Korea
    High Rigidity Special Design Robust Frame SINTELLI / /
    Zirconia Yarn Guide SINTELLI / /
    Yarn Feeder SUN Feeder (B19) SUN Feeder (B23K) Global OR Memminger
    Automatic oil Lubricator Shengsong, Taiwan Taiguan, Taiwan Can be customized
    Tube Creel Triangle Creel Creel with tube /
    4 PCS Teeth Belt MEGADYNE / /
    Micro-computer control panel (3-shift counter and 4 digital RPM counter) SINTELLI Can be customized /
    Air System Taiguan, Taiwan Shengsong, Taiwan Taishan
    Inverter TOSHIBA, Japan Delta, Taiwan Yolico, Japan
    Motor Teco, Taiwan Sintelli Delta, Taiwan
    Take Down System Fabric open take-down system Sintelli Folding & Rolling take-down system /
    Cylinder SINTELLI Japanese High Precision Alloy Steel material / /
    Machine CAM setting Single Jersey: 4 tracks Double Jersey: Dial 2 tracks, cylinder 4 tracks Exchange cam parts for structions /
    Lycra feeder SUN WAL5-4A/B SUN WAL2-4A/B Memminger
